T3AFG350
350 MHz, 2.4 GS/s, 20 Mpts, 2 Channel, 20 Vpp Function/Arbitrary Waveform Generator
Article no.
T3AFG350
- Kanały
- 2
- Rozdzielczość pionowa
- 16 bitów
- Częstotliwość
- 350 MHz
- Amplituda
- 10 V
CHF 6'994.07
incl. 8.1% VAT · CHF 6'470.00 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 2 kanały
- 16 bitów rozdzielczości pionowej
- 350 MHz Frequency
- Amplituda 10 V
- Zamiatanie
The Teledyne Lecroy T3AFG350 is a function and arbitrary waveform generator featuring a maximum frequency of 350 MHz and a sampling rate of 2.4 GS/s. It offers two channels and a memory depth of 20 million points, allowing for detailed waveform creation and manipulation. The device supports sweep and burst modes, providing flexibility in signal generation. It has a minimum transition time of 1 nanosecond and a minimum pulse width of 3.3 nanoseconds, enabling precise timing control. The amplitude output is rated at 10 volts peak-to-peak, suitable for a variety of testing applications. This waveform generator is designed to deliver accurate and stable signals across its operating range.
Technical data
Specifications
11- Kanały
- 2
- Rozdzielczość pionowa
- 16 bitów
- Częstotliwość
- 350 MHz
- Amplituda
- 10 V
- Zamiatanie
- Tak
- Burst
- Tak
- Szybkość pobierania próbek
- 2400 MS/s
- Pamięć
- 20 MPts
- Czas przejściowy min
- 1 ns
- Średnica impulsu min
- 3.3 ns
- Imax AC
