SDS6054A
500MHz; 4 channels; 5 GSa/s (10 GSa/s ESR) @ each channel; 500Mpts memory depth; 170,000 wfm/s waveform capture rate; 4 MATH traces, 8 Mpts FFT; 12.1'' touch screen (1280*800)
Article no.
SDS6054A
- Channels
- 4
- Bandwidth
- 500 MHz
- Sampling Rate/Channels
- 5000 MS/s
- Memory Depht
- 500 Mpts
CHF 6'800.85
incl. 8.1% VAT · CHF 6'291.26 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 4 channels
- 500 MHz bandwidth
- 5000 MS/s sampling rate
- 500 Mpts memory depht
- 8 Bits vertical resolution
The Siglent SDS6054A features a bandwidth of 500 MHz and offers four channels, each capable of a sampling rate of 5 GSa/s, with an equivalent sampling rate of 10 GSa/s in ESR mode. It has a memory depth of 500 Mpts, allowing for extensive data capture and analysis. The device supports a waveform capture rate of 170,000 waveforms per second, enhancing its ability to quickly process signals. It includes four MATH traces and an 8 Mpts FFT function for advanced signal analysis. The oscilloscope is equipped with a 12.1-inch touch screen display with a resolution of 1280 by 800 pixels, providing a clear and interactive user interface. The vertical resolution is 8 bits, which defines the precision of the signal measurement. This model is designed to handle complex signal processing tasks with its combination of high bandwidth, fast sampling rate, and deep memory capacity.
Video
SDS6054A
Technical data
Specifications
7- Channels
- 4
- Bandwidth
- 500 MHz
- Sampling Rate/Channels
- 5000 MS/s
- Memory Depht
- 500 Mpts
- Vertical Resolution
- 8 Bits
- Digital Channels
- Opt
- Touch Screen
- Yes
