SDS7804A H12

8 GHz; 12-bit; 4 channels; 20 GSa/s; 500Mpts memory depth; 1,000,000 wfm/s waveform capture rate; 32 Mpts FFT; Eye/Jitter Analysis(opt.); Compliance Test(opt.); 15.6'' touch screen

Article no. SDS7804A H12

Channels: 4
Bandwidth: 8000 MHz
Sampling Rate/Channels: 10000 MS/s
Memory Depht: 500 Mpts

CHF 65'279.81

incl. 8.1% VAT · CHF 60'388.35 excl. VAT

B2B prices after login

Calibration & repair at our lab in Biel/Bienne
Expert advice: +41 (0)31 312 48 48

Overview

Description

4 channels
8000 MHz bandwidth
10000 MS/s sampling rate
500 Mpts memory depht
12 Bits vertical resolution

The Siglent SDS7804A H12 features a bandwidth of 8 GHz and offers 12-bit vertical resolution across its 4 channels. It supports a maximum sampling rate of 20 GSa/s and provides a memory depth of 500 million points, enabling extensive data capture for detailed analysis. The device is capable of capturing waveforms at a rate of 1,000,000 waveforms per second, facilitating rapid data acquisition. It includes a 32 million points FFT for frequency domain analysis and offers optional Eye/Jitter Analysis and Compliance Test functionalities. The oscilloscope is equipped with a 15.6-inch touch screen, enhancing user interaction and control. Sampling rate per channel is 10,000 MS/s, and the memory depth per channel is 500 Mpts. This combination of features supports high-resolution, high-speed signal measurement and analysis.
