SDS7604A H12

6GHz; 12-bit; 4 channels; 20 GSa/s; 500Mpts memory depth; 1,000,000 wfm/s waveform capture rate; 32 Mpts FFT; Eye/Jitter Analysis(opt.); Compliance Test(opt.); 15.6'' touch screen

Article no. SDS7604A H12

Channels: 4
Bandwidth: 6000 MHz
Sampling Rate/Channels: 10000 MS/s
Memory Depht: 500 Mpts

CHF 37'457.18

incl. 8.1% VAT · CHF 34'650.49 excl. VAT

B2B prices after login

Calibration & repair at our lab in Biel/Bienne
Expert advice: +41 (0)31 312 48 48

Overview

Description

4 channels
6000 MHz bandwidth
10000 MS/s sampling rate
500 Mpts memory depht
12 Bits vertical resolution

The Siglent SDS7604A H12 features a bandwidth of 6 GHz and offers 12-bit vertical resolution across its 4 channels. It supports a maximum sampling rate of 20 GSa/s and provides a memory depth of 500 Mpts, enabling detailed signal analysis. The device is capable of capturing waveforms at a rate of 1,000,000 wfm/s, which facilitates rapid data acquisition. It includes a 15.6-inch touch screen for user interaction and supports a 32 Mpts FFT for frequency domain analysis. Optional features include Eye/Jitter Analysis and Compliance Test capabilities. The sampling rate per channel is 10,000 MS/s, and the memory depth per channel is 500 Mpts. This oscilloscope is designed to handle high-speed signal measurements with precision and efficiency.
