T3DSO4208L-HD
2GHz, 10 GS/s ESR, 8 CH, 500 Mpts/Ch (Single Channel), 12-Bit HD Low Profile Oscilloscope
Article no.
T3DSO4208L-HD
- Channels
- 8
- Bandwidth
- 2000 MHz
- Sampling Rate/Channels
- 10000 MS/s
- Memory Depht
- 125 Mpts
CHF 50'947.53
incl. 8.1% VAT · CHF 47'130.00 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 8 channels
- 2000 MHz bandwidth
- 10000 MS/s sampling rate
- 125 Mpts memory depht
- 12 Bits vertical resolution
The Teledyne Lecroy T3DSO4208L-HD is a high-definition oscilloscope featuring an 8-channel configuration with a bandwidth of 2 GHz. It offers a sampling rate of 10 GS/s per channel, enabling detailed signal analysis. Each channel is equipped with a memory depth of 500 Mpts, allowing for extensive data capture and review. The device provides a vertical resolution of 12 bits, contributing to precise measurement accuracy. This low-profile oscilloscope supports single-channel operation with a memory depth of 125 Mpts. It does not include a touch screen interface. The combination of these specifications makes the T3DSO4208L-HD suitable for applications requiring high-speed data acquisition and detailed waveform analysis.
Technical data
Specifications
8- Channels
- 8
- Bandwidth
- 2000 MHz
- Sampling Rate/Channels
- 10000 MS/s
- Memory Depht
- 125 Mpts
- Vertical Resolution
- 12 Bits
- Digital Channels
- Opt
- Touch Screen
- No
- Imax AC
