HDO4054A-MS
500 MHz, 4+16 Ch, 12-Bit, 10 GS/s, 12.5 Mpts/Ch HD Mixed-Signal Oscilloscope with 12.1" WXGA Color D
Article no.
HDO4054A-MS
- Channels
- 4
- Bandwidth
- 500 MHz
- Sampling Rate/Channels
- 10000 MS/s
- Memory Depht
- 25 Mpts
CHF 30'603.11
incl. 8.1% VAT · CHF 28'310.00 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 4 channels
- 500 MHz bandwidth
- 10000 MS/s sampling rate
- 25 Mpts memory depht
- 12 Bits vertical resolution
The Teledyne Lecroy HDO4054A-MS is a high-performance mixed-signal oscilloscope featuring a bandwidth of 500 MHz and four analog channels. It offers a sampling rate of 10 GS/s per channel, enabling detailed signal analysis with a vertical resolution of 12 bits. Each channel is equipped with a memory depth of 12.5 million points, providing extensive data capture capabilities. The device also includes 16 digital channels, enhancing its mixed-signal functionality. The oscilloscope is equipped with a 12.1-inch WXGA color display that supports touch screen operation, facilitating intuitive user interaction. With a total memory depth of 25 million points, it supports complex waveform acquisition and analysis. This model is designed to handle a wide range of testing scenarios requiring precise timing and signal integrity measurements.
Technical data
Specifications
8- Channels
- 4
- Bandwidth
- 500 MHz
- Sampling Rate/Channels
- 10000 MS/s
- Memory Depht
- 25 Mpts
- Vertical Resolution
- 12 Bits
- Digital Channels
- Yes
- Touch Screen
- Yes
- Imax AC
