SSG5040X
9 k - 4 GHz; -140 dBm ~ +26 dBm; 0.001Hz frequency resolution, Phase noise -120 dBc/Hz @1 GHz, 20 kHz offset; 5 inch TFT touch-screen
Article no.
SSG5040X
- Channels
- 1
- Frequency
- 4000 MHz
- Amplitude
- 26 dBm
CHF 5'561.38
incl. 8.1% VAT · CHF 5'144.66 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 1 channels
- 4000 MHz frequency
- 26 dBm amplitude
The Siglent SSG5040X operates within a frequency range of 9 kHz to 4 GHz, offering a maximum frequency of 4000 MHz. It features a frequency resolution of 0.001 Hz, allowing for precise signal generation and analysis. The device has a phase noise specification of -120 dBc/Hz at 1 GHz with a 20 kHz offset, ensuring stable and low-noise output. Its amplitude range extends from -140 dBm to +26 dBm, with a maximum amplitude of 26 dBm. The SSG5040X is equipped with a 5-inch TFT touch-screen, providing an intuitive interface for user interaction. This model is designed by Siglent and is identified by the product code SSG5040X.
Video
SSG5040X
Technical data
Specifications
3- Channels
- 1
- Frequency
- 4000 MHz
- Amplitude
- 26 dBm
