SDG7052A
500MHz; 2 differential/single ended output channels; 5 GSa/s sampling rate; 14-bit vertical resolution; Arb-Waveform length: 64 pts ~ 512 Mpts; 5 inch touch screen
Article no.
SDG7052A
- Channels
- 2
- Vertical Resolution
- 14 Bits
- Frequency
- 500 MHz
- Amplitude
- 6 V
CHF 10'211.77
incl. 8.1% VAT · CHF 9'446.60 excl. VAT
- Calibration & repair at our lab in Biel/Bienne
- Expert advice: +41 (0)31 312 48 48
Overview
Description
- 2 channels
- 14 Bits vertical resolution
- 500 MHz frequency
- 6 V amplitude
- Sweep
The SDG7052A from Siglent features a maximum frequency of 500 MHz and offers two differential or single-ended output channels. It supports a high sampling rate of 5 GSa/s and provides a 14-bit vertical resolution for precise signal generation. The arbitrary waveform length ranges from 64 points up to 512 million points, allowing for extensive waveform customization. This model includes a 5-inch touch screen for user-friendly operation. The device supports sweep and burst functions, enhancing its versatility in various applications. It has a sampling rate of 2500 MS/s and a memory depth of 512 Mpts, enabling detailed waveform storage and playback. The minimum transition time is 0.5 ns, and the minimum pulse width is 1 ns, supporting high-speed signal transitions. The maximum amplitude output is 6 V.
Video
SDG7052A
Technical data
Specifications
10- Channels
- 2
- Vertical Resolution
- 14 Bits
- Frequency
- 500 MHz
- Amplitude
- 6 V
- Sweep
- Yes
- Burst
- Yes
- Sampling Rate
- 2500 MS/s
- Memory
- 512 MPts
- Transition time min
- 0.5 ns
- Pulse Width min
- 1 ns
