AWG-4012-2M
2ch 1,2Gs/s AWG- 2Ms memory - 300MHz AFG - 6Vpp
Article no.
AWG-4012-2M
- Channels
- 2
- Vertical Resolution
- 16 Bits
- Frequency
- 300 MHz
- Amplitude
- 6 V
Price on request
The price depends on configuration and options. Tell us what you need and you get a quote within one working day.
- Personal offer from our team in Biel/Bienne
- Calibration & repair at our lab
Overview
Description
- 2 channels
- 16 Bits vertical resolution
- 300 MHz frequency
- 6 V amplitude
- Sweep
The AWG-4012-2M from Active Technologies is a 2-channel arbitrary waveform generator featuring a sampling rate of 1.2 Gigasamples per second and a memory depth of 2 million points. It operates with a maximum frequency of 300 MHz and provides an amplitude output of up to 6 volts peak-to-peak. The device supports sweep and burst modes, allowing for versatile signal generation. It has a minimum transition time of 2 nanoseconds and a minimum pulse width of 2.5 nanoseconds, enabling precise control over waveform characteristics. This model is designed to deliver high-speed and high-resolution signal output suitable for various testing and measurement applications. The combination of its sampling rate, memory depth, and frequency range makes it suitable for generating complex waveforms with fine detail and accuracy.
Technical data
Specifications
10- Channels
- 2
- Vertical Resolution
- 16 Bits
- Frequency
- 300 MHz
- Amplitude
- 6 V
- Sweep
- Yes
- Burst
- Yes
- Sampling Rate
- 1200 MS/s
- Memory
- 2 MPts
- Transition time min
- 2 ns
- Pulse Width min
- 2.5 ns
